Balanced Fresh Air Exchange Since 1976 CAC029376

ERV System Installation

Filtration and purification treat the air you already have. An ERV replaces it, bringing outdoor air in and stale indoor air out, with a core that transfers heat and moisture between the two streams so ventilating does not hand your cooling system a humidity problem.

BalancedIn Equals Out
Heat & MoistureWhat The Core Transfers
MeasuredNot Assumed
CAC029376State Licensed
Balanced Airflow Designed Core Performance Assessed Airflow Measured, Not Assumed HVAC Integration Verified Controls Set For Occupancy

The Straight Answer

Sealed Tight, Nowhere To Breathe

Modern Florida construction is deliberately airtight. That keeps cooling in and cuts the power bill, and the same move traps indoor pollutants, odours and moisture with no route out and nothing fresh coming in to dilute them.

An ERV addresses that without giving up the benefit. It exchanges indoor air for outdoor air continuously, and the recovery core passes heat and moisture between the outgoing and incoming streams, so incoming air arrives preconditioned rather than raw.

In a Florida summer that distinction is the whole product. Unconditioned outdoor air is hot and close to saturated, and putting it straight into a cooled building is how ventilating turns into a humidity problem.

The Specifics

  • Brings in: Filtered outdoor air
  • Transfers: Heat and moisture
  • Airflow: Balanced, supply equals exhaust
  • Runs: Continuously at low rate, or scheduled
  • Install includes: Airflow measurement and calibration
  • Versus HRV: An ERV also moves moisture
  • Licence: Florida CAC029376
  • Phone: 386-361-5500

What You Notice

Signs The Air Is Not Being Replaced

These get reported as air conditioning faults, and chasing them as cooling problems leads nowhere, because the equipment is working. The air is clean and simply exhausted.

Stale, Used-Feeling Air

Most obvious walking back in after being out for a few hours. You stop noticing it while you are in it, which is part of the problem.

Odours That Linger For Hours

Cooking and household smells that fade slowly rather than clearing, because nothing is carrying them out of the building.

Symptoms Indoors, Easing Outdoors

Irritants being recirculated rather than diluted. The pattern points at the air itself rather than at the season.

Uncirculated Even When Running

The system moves air around the building constantly. Moving it is not the same as replacing it, and no amount of running will exchange anything.

Worth knowing: ventilation is the least understood part of indoor air, and it is often not the answer. If the complaint is moisture alone, a dehumidifier is more direct and usually cheaper to run. If it is dust or pollen, filtration is cheaper still. An ERV earns its place when the air genuinely needs replacing rather than cleaning or drying, and that is a narrower case than it is often sold as.

Why Balance Matters

Three Ways To Get Air Moving

All three move air. Only one of them replaces it at a controlled rate without changing the pressure inside the building, and pressure is where the trouble starts.

What You Are Comparing Open a window Run exhaust fans Balanced ERV
What it does Lets air move both ways, uncontrolled Pushes air out only Supplies and exhausts at matched rates
Effect on pressure Whatever the wind decides Negative. The building is now sucking Stable, because in equals out
Where replacement air enters The window, and the gaps too Wall cavities, attic, around frames Where you intended, filtered
Humidity imported All of it, unconditioned All of it, through gaps you cannot see Reduced, because the core preconditions it
Cost to run Free, then paid for in cooling Cheap, then paid for in cooling Modest, and it raises cooling load a little
Worth knowing: ask for the measured supply and exhaust numbers at handover. Balanced means verified, and measurement is the step most easily skipped on a ventilation install, because nothing looks wrong without it. A system that was intended to be balanced and never checked is the common failure here, and you cannot see it or feel it. If nobody offers you figures, that is the question to press.

The Total Comfort Way

What Installation Involves

Five steps, and the last one is the one that decides whether the first four amounted to anything.

STEP 01

Ventilation Design

A balanced rate worked out for the property and how it is occupied, rather than a default figure applied because it usually fits.

STEP 02

Duct Integration

Integrated with the existing duct system so the ERV and the HVAC work together instead of fighting each other for the same air paths.

STEP 03

Core Performance Assessed

The moisture transfer core is what makes an ERV worth having in this climate rather than an expensive way to import humidity, so its performance is checked, not assumed.

STEP 04

Wiring And Controls

Configured for how the building is actually used. A holiday rental and a full-time family home need different settings, and neither is the factory default.

STEP 05

Measured And Calibrated

Supply and exhaust airflow measured and the system calibrated. This is the step that separates a balanced system from one merely intended to be balanced.

Common Questions

Ventilation Questions

That is the right question to ask in Florida, and it is the concern an ERV exists to answer. The recovery core transfers moisture between the outgoing and incoming streams, so incoming air is preconditioned before it reaches the building.

Fresh air without an ERV does import humidity. Open windows and exhaust fans pulling air through gaps both do exactly that. The core is the difference between ventilating and importing weather.

Because they only push air out. Removing air without replacing it leaves the building at negative pressure, so it draws replacement air in through whatever gaps it can find. Wall cavities, attic penetrations, around window frames.

That air is unfiltered, uncontrolled, and in this climate humid. You end up ventilating and importing moisture in the same breath, which is worse than doing nothing.

Yes, somewhat, and we would not claim otherwise. You are conditioning air that used to be outdoors.

The recovery core keeps the increase modest rather than severe by preconditioning incoming air with the air on its way out. Against achieving the same ventilation by opening windows or running exhaust fans, an ERV is considerably the cheaper route. Against not ventilating at all, it costs more.

Both recover heat. An ERV also transfers moisture.

In cold dry climates an HRV often suffices, because humidity is a lesser concern. Here, moisture transfer is the point. What incoming air carries matters at least as much as its temperature, which is why we fit ERVs in this climate and not HRVs.

They solve different problems. Filtration removes particles from the air you have. Purification treats contaminants in it. Ventilation replaces the air itself.

If the complaint is dust or allergens, the first two address it and cost less. If it is staleness, lingering odours, or the sense that the air never changes, no amount of filtering helps, because the air is clean and exhausted at the same time.

Usually continuously at a low rate, or on a schedule, rather than cycling with the air conditioning.

Controls are configured at installation to suit the property and its occupancy. Getting that wrong in either direction wastes money, so it is worth telling us how the building is really used rather than how it was designed to be used.

ERV System Installation

Fresh Air, Without The Weather.

Licensed since 1976 under Florida CAC029376. Balanced rate designed for the property, core performance assessed, controls set for how the building is actually occupied, and supply and exhaust airflow measured at handover rather than assumed. If a dehumidifier or better filtration is the honest answer instead, we will say so.
